| XW100PO Parallel opening window | XW110PO Parallel opening window | |
| Design | ||
| Opening | Parallel opening | Parallel opening |
| Opening option | Manually, motorised | Manually, motorised |
| Basic depth(mm) | 98 | 108 |
| Vent frame depth(mm) | 108 | 118 |
| Face width of frame(mm) | 19 | 19 |
| Face width of vent frame(mm) | 82 | 82 |
| Face width of meeting stile(mm) | No | No |
| Face width of mullion(mm) | 165 | 165 |
| Reinforcement mullion | No | No |
| Concealed motor | Yes | Yes |
| Surface finish | MED, powder coating | MED, powder coating |
| Fixed lights | Yes | Yes |
| Vent data | ||
| Min.-max. vent height(mm),manually control, depending on window type | 500-3000 | 500-3000 |
| Min.-max. vent width(mm),manually control, depending on window type | 400-1500 | 400-1500 |
| Min.-max. vent height(mm),motorised control, depending on window type | 600-3000 | 600-3000 |
| Min.-max. vent width(mm),motorised control, depending on window type | 500-1500 | 500-1500 |
| Max. vent weight(Kg) | 200 | 200 |
| Min.-max. glass thickness(mm) | Vent: 27.5-30 | Vent: 37.5-40 |
| Frame: 24-74 | Frame: 34-84 | |
| Implement scenario | ||
| Façade insert unit | Yes | Yes |
| Conservatory insert unit | Yes | Yes |
| Parameter | ||
| U values in W/(㎡·K) | 2.5 | 1.8 |
| Sound reduction(dB), depending on glazing type | 35 | 37 |
| Air permeability(m3/(m.h)) | 0.21 | 0.21 |
| Water tightness(Pa) | 1000 | 1000 |
| Wind load resistance(KPa) | ≤5 | ≤5 |
