| XD55IN Door | XD55OU Door | ||
| Design | |||
| Opening | Inwards opening | Outwards opening | |
| Opening type | Single, double, unequal double leaf | Single, double, unequal double leaf | |
| Basic depth(mm) | 56 | 56 | |
| Vent frame depth(mm) | 56 | 56 | |
| Face width of frame, low threshold (mm) | 19.4 | 16 | |
| Face width of vent frame, low threshold (mm) | 77.6 | 104 | |
| Face width of frame, high threshold (mm) | 80 | 53.6 | |
| Face width of vent frame, high threshold (mm) | 77.6 | 104 | |
| Threshold height(mm) | Low threshold: 19 | Low threshold: 11 | |
| High threshold: 80 | High threshold: 80 | ||
| Barrel hing | Yes | Yes | |
| T profile | No | No | |
| Meeting stile | No | No | |
| Surface finish | MED, powder coating | MED, powder coating | |
| Fixed lights | Yes | Yes | |
| Leaf data | |||
| Min.-max. leaf height(mm),depending on door type | 2000-3000 | 2000-3000 | |
| Min.-max. leaf width(mm),depending on door type | 550-1200 | 550-1200 | |
| Max. leaf weight(Kg) | 250 | 250 | |
| Min.-max. glass thickness(mm) | 7.5-32.5 | 7.5-32.5 | |
| Implement scenario | |||
| Façade insert unit | Yes | Yes | |
| Conservatory insert unit | Yes | Yes | |
| Parameter | |||
| U values in W/(㎡·K) | 2.6 | 2.6 | |
| Sound reduction(dB), depending on glazing type | 33 | 33 | |
| Air permeability(m3/(m.h)) | 0.5 | 0.5 | |
| Water tightness(Pa) | 300 | 700 | |
| Wind load resistance(KPa) | ≤5 | ≤5 | |
| Burglary resistance | RC3 | RC3 | |
