| Category | Results | Standard |
|---|---|---|
| Deflection Framing member 1 | Stile at handle side: 1/2373 | |
| Deflection Framing member 2 | Rail at bottom: 1/3775 | |
| Wind Pressure | ±800Pa | AS/NZS 4420.1-2016 section 3 |
| Operating Force | Initial Movement 54N / Maintain Movement 4N | AS/NZS 4420.1-2016 section 4 |
| Air Infiltration at ±75Pa | at +75Pa: 0.95L/s.㎡ / at -75Pa: 1.27L/s.㎡ | AS/NZS 4420.1-2016 section 5 |
| Water Penetration | No water penetration at 450Pa or less | AS/NZS 4420.1-2016 section 6 |
| Ultimate Strength Test Pressure | ±2000Pa with no collaspe | AS/NZS 4420.1-2016 section 7 |
